PPC-5150A-H61-i3/R-R20 - IEI 15” 450 cd/m2 XGA heavy industrial All In One Panel PC with POS-H61, Core i3 Dual Core 2xxxT CPU (Above 2.5GHz), TDP 35W, 2GB DDR3 RAM*2, Silver color, AC input PSU, touch screen, R20
● High brightness TFT-LCD panel with LED backlight
● Multiple storage options: 2.5"" SATA HDD, CF slot and mSATA
● Dual Ethernet provides continuous network service and allows sharing among different workgroups in two different subnets
● Optional PCI / PCIe x 1 expansion slot
● Optional slim type CD-ROM drive bay
● Robust aluminum front bezel and metal casing
● IP 66 compliant front panel
● IEI One Key Recovery solution allows you to create rapid OS backup and recovery (over 4GB storage capacity)
| LCD Size | 15" |
| Max Resolution | 1024(W) x 768(H) |
| Brightness (cd/m²) | 450 |
| Contrast Ratio | 800:1 |
| LCD Color | 16.2M |
| Pixel Pitch (mm) (HxV) | 0.297(H) x 0.297(V) |
| Viewing Angle (V/H) | 150°/160° |
| Backlight MTBF (hrs) | 50,000 |
| Touch Screen | Resistive Type 5-Wire with RS-232 interface |
| Touch Controller | DMC 9000 |
| SBC | POS-H61 |
| CPU | 2nd/3rd Generation Intel® Core™ Core™ i7/ i5/ i3, Petium® and Celeron® processor |
| Chipset | Intel® H61 |
| RAM | Two 204-pin DDR3 SO-DIMM slots (Max. 16G) |
| Ethernet | Realtek RTL8111E PCIe GbE controller supporting ASF 2.0 |
| Audio Codec | Realtek ALC662 audio codec |
| I/O Ports and Switches | 4 x RS-232 COM Port 1 x RS-232/422/485 Port 2 x RJ-45 for LAN Port 4 x USB 2.0, 2 x USB 3.0 on rear 1 x VGA Port 1 x Audio (Line-out, MIC-in) 2 x SFP Fiber LAN 1 x Power Switch 1 x AT / ATX Switch 1 x PCI/PCIe Slot |
| HDD Driver Bay | 1 x 2.5” SATA/IDE HDD bay with anti-shock |
| SSD | CF Type II, mSATA (SATA2 signal) |
| CD-ROM Drive Bay | SATA Slim Type CD-ROM Bay |
| Expansion Slot | Either 1 x PCI slot or 1 x PCIe slot 1 x PCIe Mini card |
| Front Panel Construction | Aluminum |
| Chassis Contruction | Heavy-duty Steel |
| Mounting | Panel, Wall, Rack, Stand and Arm VESA 100mm x 100mm |
| Front Panel Color | Silver (Pantone 8001C) |
| Dimensions (WxHxD) (mm) | 410 x 309 x 110.5 |
| Cut Out Dimensions (WxH) (mm) | 387 x 286 |
| Net / Gross Weight | 7 Kg / 11 Kg |
| System Cooling | Active with Fan |
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -30°C ~ 70°C |
| IP Rating | Front IP66 Compliant |
| Vibration | 5~17Hz, 0.1 double amplitude displacement 17~640Hz 1.5G acceleration peak to peak |
| Shock | 10G acceleration part to part (11ms) |
| Power Supply | AC Input ATX power supply - P/N: 63030-010220-100-RS - 220W power supply - Input: 90VAC~264VAC, 50/60Hz - Output(max.): 3.3V@10A, 5V@14A, 12V@10A, -12V@0.3A DC Input ATX power supply - P/N: ACE-4520C-RS - 200W power supply - Input: 24 VDC(18~36 VDC) - Output(max.): 3.3V@12A, 5V@12A, 12V@15.4A, -12V@0.5A |
